Description
NovaStar TB40 Sending Box – 1.3 Million Pixels | Dual-Mode Synchronous & Asynchronous LED Controller with HDMI Preview for LED Display Screens
Package Included
| Version | Package Included |
|---|---|
| TB40 | TB40 Multimedia Player |
About this item
- High-performance LED screen controller supporting HDMI, DVI, and Ethernet input/output
- Compatible with multiple LED module pixel pitches, up to 4096×4096 resolution
- NTP/GPS sync, 4G support, dual HDMI splicing playback
- Compact design with efficient heat dissipation
- Ideal for indoor/outdoor fixed installations and rental displays
Order & Logistics
- Lead Time: 2–5 business days
- Packing: Cardboard box
- Shipping: Local warehouse 3–7 days; HQ 7–25 days standard / 3–10 days express
Key Specifications
- Input Ports: 1×HDMI, 1×DVI, 2×Ethernet
- Output Ports: 1×Main, 1×Backup
- Supported Resolutions: Up to 4096×4096
- Control Method: USB, Network, WiFi
- Power Supply: AC 100–240V
- Operating Temp: -20°C to 60°C
Usage Notes / Installation Tips
- Always power off before connecting/disconnecting cables
- Use shielded network cables for stability
- Ensure adequate ventilation
Technical Specifications
| Specification | TB10 Plus | TB20 Plus | TB30 | TB40 | TB50 | TB60 |
|---|---|---|---|---|---|---|
| CPU | 4 Core A35/1.4GHz | 4 Core A35/1.4GHz | 4 Core A55/1.8GHz | 4 Core A55/1.8GHz | 4 Core A55/1.8GHz | 4 Core A55/1.8GHz |
| Storage | 2GB+32GB | 2GB+32GB | 1GB+32GB | 1GB+32GB | 1GB+32GB | 1GB+32GB |
| Decode | 4K 60fps | 4K 60fps | 4K 60fps | 4K 60fps | 4K 60fps | 4K 60fps |
| OS | Android 10 | Android 10 | Android 11 | Android 11 | Android 11 | Android 11 |
| Max Cap | 0.65M pixels | 0.65M pixels | 0.65M pixels | 1.3M pixels | 1.3M pixels | 2.3M pixels |
| Max Res | 2048×2048 / 8192×2084 | 2048×2048 / 8192×2084 | 4096×4096 | 4096×4096 | 4096×4096 | 4096×4096 |
| Video | 1x4K / 3x1080P / 8x720P / 16x480P / 20x360P | 1x4K / 3x1080P / 8x720P / 16x480P / 20x360P | 1x4K / 2x1080P / 4x720P / 4x480P / 6x360P | 1x4K / 2x1080P / 4x720P / 4x480P / 6x360P | 1x4K / 2x1080P / 4x720P / 4x480P / 6x360P | 1x4K / 2x1080P / 4x720P / 4x480P / 6x360P |
| Ports | 1 Main + 1 Backup | 1 Main + 1 Backup | 1 Main + 1 Backup | 2 Main | 2 Main | 4 Main |
| Sync | NTP, GPS | NTP, GPS | NTP, GPS | NTP, GPS | NTP, GPS | NTP, GPS |
| Dual Mode | X | √ | X | √ | √ | √ |
| HDMI | X | X | X | √ 1080p, up to level 8 | √ 1080p, up to level 8 | √ 1080p, up to level 8 |
| Audio | √ | √ | √ | √ | √ | √ |
| Sensor | 1 aviation plug | 1 aviation plug | 2 aviation plugs | 2 aviation plugs | 2 aviation plugs | 2 aviation plugs |
| USB | √ USB2.0 | √ USB2.0 | √ USB3.0 | √ USB3.0 | √ USB3.0 | √ USB3.0 |
| LAN | 100 Mbps | 100 Mbps | 1000 Mbps | 1000 Mbps | 1000 Mbps | 1000 Mbps |
| WiFi | 2.4G AP & STA | 2.4G AP & STA | 2.4G AP & STA | 2.4G AP & STA | 2.4G AP & STA | 2.4G AP & STA |
| 4G | Support (Option) | Support (Option) | Support (Option) | Support (Option) | Support (Option) | Support (Option) |
| 5G | X | X | Support (Option) | Support (Option) | Support (Option) | Support (Option) |
| Viplex | √ | √ | √ | √ | √ | √ |
| SDK | √ | √ | √ | √ | √ | √ |
| Material | Metal Case | Metal Case | Metal Case | Metal Case | Metal Case | Metal Case |
| Power | AC 100~240V | AC 100~240V | AC 100~240V | AC 100~240V | AC 100~240V | AC 100~240V |
| Certifications | CE EMC, LVD, ROHS, FCC, FCC ID, IC, RED, UKCA, UL, RCM, PSE | CE EMC, LVD, ROHS, FCC, FCC ID, IC, RED, UKCA, UL, RCM, PSE | CQC, SRRC, RoHS, CE EMC, LVD, ROHS, FCC, FCC ID, IC, RED, UKCA, UL, RCM, PSE | CE EMC, LVD, ROHS, FCC, FCC ID, IC, RED, UKCA, UL, RCM, PSE | CE EMC, LVD, ROHS, FCC, FCC ID, IC, RED, UKCA, UL, RCM, PSE | CE EMC, LVD, ROHS, FCC, FCC ID, IC, RED, UKCA, UL, RCM, PSE |
Applications
- Fixed LED billboards
- Rental stage LED screens
- Indoor/outdoor advertising
- Conference / exhibition displays
