Description
ID-C Series – P1.53 COB Indoor LED Modules | 320×160mm | Front Service | Standard Modules | Command Rooms & Meeting Spaces | MOQ: 100 pcs
About this item
- Ultra Fine Pitch COB Indoor LED Modules – P1.53 COB Indoor LED Modules are designed for command centers, control rooms, premium indoor LED video walls, and professional display projects requiring exceptional image clarity, high pixel density, and reliable long-term operation.
- Advanced Flip-Chip COB Technology – Featuring flip-chip LED technology and COB film encapsulation, the module provides a smooth protected surface, reduced glare, improved light uniformity, and stable visual performance for demanding indoor applications.
- High Density Visual Performance – With 1.53mm pixel pitch, 208×104 module resolution, 422,753 pixels/m² density, and 3840Hz refresh rate, the module delivers detailed close-viewing images with excellent grayscale performance and color consistency.
- Professional Front Service Structure – The standardized 320×160mm module design supports efficient cabinet installation, convenient maintenance, and compatibility with mainstream indoor LED cabinet systems.
- High Consistency Display Architecture – Optimized COB design provides excellent surface uniformity, reduced pixel visibility, and stable display performance across large professional LED video walls.
- Mission-Critical Applications – Ideal for command centers, security monitoring rooms, emergency dispatch centers, financial trading floors, broadcast studios, executive boardrooms, and premium indoor display projects.
Package Included
| Version | Package Included |
| MOQ. 100pcs Pack | 100 × P1.53 320×160mm COB Indoor LED Module 50 × 5V Power Cable 1-to-2 Split 100 × Flat Data Cable |
Order & Logistics
Lead Time
- ID-S Series and ID-G Series usually ship within 3–5 business days.
- ID-GI Series and ID-C Series usually ship within 15–20 business days.
Shipping Note
- This series enjoys our Free Shipping Policy for orders over $399.
- Shipping Policy for ID Series: All ID Series modules are covered by our Free Shipping Policy on orders over US$399. Orders will be shipped from local warehouses when stock is available, or directly from China otherwise.
- For faster delivery, express options like DHL/UPS/FedEx are available during checkout.
- HQ Fulfillment: Standard delivery takes 9–18 business days, while Express delivery takes 5–9 business days.
Protection & Design Features
- Advanced Flip-Chip COB Technology – Chip-on-Board (COB) packaging technology provides excellent light uniformity, superior color consistency, minimized pixel spacing visibility, and dependable long-term performance.
- COB Film Encapsulation Surface – The protected surface improves durability, reduces glare, and maintains stable image quality for professional indoor display environments.
- Standard Front Service Module Structure – The 320×160mm front service architecture supports efficient cabinet installation, simplified maintenance, and convenient module replacement.
- High Consistency Display Architecture – Designed to maintain excellent grayscale performance, visual uniformity, and stable operation across large ultra fine pitch LED video wall installations.
Installation Tips
- Confirm cabinet size, module layout, receiving card configuration, power supply capacity, mounting structure, and front service requirements before installation.
- Install P1.53 COB Indoor LED Modules according to the cabinet layout and ensure each module is accurately aligned and securely fixed.
- Connect signal and power cables according to the cabinet wiring plan and receiving card configuration.
- Check input voltage, power polarity, signal direction, grounding, and cabinet flatness before powering on the LED display system.
- For front service maintenance, remove and replace the COB LED module from the front side using proper tools and anti-static handling procedures.
- Avoid scratching, pressing, bending, or impacting the COB surface during transportation, installation, and maintenance.
Technical Specifications
| Specification | Value |
| Module Size | 320 × 160mm |
| Pixel Pitch | 1.53mm |
| LED Technology | Flip-Chip LED |
| Module Resolution | 208 × 104 pixels |
| Pixel Density | 422,753 pixels/m² |
| Surface Technology | COB Film Encapsulation |
| Surface Hardness | 4H |
| Compatible Cabinet Size | 640 × 480 × 59mm |
| Cabinet Weight | 7.5kg per cabinet |
| Cabinet Resolution | 416 × 312 pixels |
| Cabinet Material | Die-Cast Aluminum |
| Circuit Design | Common-Cathode Circuit Design |
| Flash Calibration Storage | Supported |
| Brightness | 600cd/m² |
| Refresh Rate | 3840Hz |
| Contrast Ratio | 10,000:1 (dark-room conditions) |
| Color Temperature | 9300K standard |
| Viewing Angle | H:160° / V:160° |
| Input Voltage | AC 100–240V, 50/60Hz |
| Maximum Power Consumption | 88W per cabinet |
| Maintenance Type | Full Front Service |
| Life Span at 50% Brightness | 100,000 hours |
| Operating Temperature / Humidity | -10°C to 40°C / 10%–90% RH |
| Storage Temperature / Humidity | -20°C to 60°C / 10%–90% RH |
| Certifications | CCC, EMC Class A, RoHS, CQC |
| Application Environment | Indoor |
Applications
- Professional COB Indoor LED Displays: High-end LED solutions requiring excellent image consistency, reduced glare, and reliable long-term operation.
- Mission-Critical Display Systems: Command centers, control rooms, security monitoring centers, emergency dispatch centers, and financial trading displays.
- Broadcast & Production Applications: Broadcast studios, television production environments, and camera-friendly LED display projects.
- Premium Commercial Displays: Executive boardrooms, corporate experience centers, premium conference rooms, museums, and professional AV LED projects.
