Description
48V LED Power Supply, 175–265V Input, 100W–400W, Constant Voltage Transformer, IP67 Waterproof SMPS, CE/RoHS/FCC — UK/EU Plug & Wire Leads Options
Package Included
| Version | Package Included |
|---|---|
| 100W UK Plug | 1 × 48V LED Power Supply Adapter, User Manual |
| 100W EU Plug | 1 × 48V LED Power Supply Adapter, User Manual |
| 100W Wire Leads (3-core) | 1 × 48V LED Power Supply Adapter, User Manual |
| 150W UK Plug | 1 × 48V LED Power Supply Adapter, User Manual |
| 150W EU Plug | 1 × 48V LED Power Supply Adapter, User Manual |
| 150W Wire Leads (3-core) | 1 × 48V LED Power Supply Adapter, User Manual |
| 200W UK Plug | 1 × 48V LED Power Supply Adapter, User Manual |
| 200W EU Plug | 1 × 48V LED Power Supply Adapter, User Manual |
| 200W Wire Leads (3-core) | 1 × 48V LED Power Supply Adapter, User Manual |
| 300W UK Plug | 1 × 48V LED Power Supply Adapter, User Manual |
| 300W EU Plug | 1 × 48V LED Power Supply Adapter, User Manual |
| 300W Wire Leads (3-core) | 1 × 48V LED Power Supply Adapter, User Manual |
| 350W UK Plug | 1 × 48V LED Power Supply Adapter, User Manual |
| 350W EU Plug | 1 × 48V LED Power Supply Adapter, User Manual |
| 350W Wire Leads (3-core) | 1 × 48V LED Power Supply Adapter, User Manual |
| 400W UK Plug | 1 × 48V LED Power Supply Adapter, User Manual |
| 400W EU Plug | 1 × 48V LED Power Supply Adapter, User Manual |
| 400W Wire Leads (3-core) | 1 × 48V LED Power Supply Adapter, User Manual |
About this item
- Universal input voltage 175–265V AC, compatible worldwide
- Converts AC to stable DC output
- Compact design for home and professional use
- Suitable for LED strips, CCTV, routers, pumps, car accessories, DIY electronics
- Safe and reliable with overload, short-circuit, and over-voltage protection
Order & Logistics
- Lead Time: Ships within 1–3 business days
- Packing: Protective cardboard box with user manual
- Ships from local warehouses (US, Canada, UK, Germany) with delivery in 3–7 days. In rare cases, shipment may be fulfilled from central warehouse if local stock is unavailable(9–18 days standard or 5–9 days express.)
Key Specifications
- Input Voltage: 175–265V AC, 50/60Hz
- Output Voltage / Wattage: 48V DC / 100W–400W
- Package Qty: 1-Pack
- Plug Type: UK Plug / EU Plug / Wire Leads (3-core)
- Protection: Overload, Short-circuit, Over-voltage
| Model | PFH-100-48 | PFH-150-48 | PFH-200-48 | PFH-300-48 | PFH-350-48 | PFH-400-48 |
|---|---|---|---|---|---|---|
| Input voltage range | 90–140V AC | 90–140V AC | 90–140V AC | 90–140V AC | 90–140V AC | 90–140V AC |
| Output power | 100W | 150W | 200W | 300W | 350W | 400W |
| Rated output voltage | 48V DC | 48V DC | 48V DC | 48V DC | 48V DC | 48V DC |
| Rated output current | - | - | - | - | - | 8.33A |
| Output current range | - | - | - | - | - | 0–8.33A |
| Weight | 0.7 kg | 0.8 kg | 0.85 kg | 0.98 kg | 1.03kg | 1.54 kg |
| Outer box dimensions and packaging |
180× 69 × 43mm | 217× 69 × 43mm | 217× 69 × 43mm | 220× 73 × 45mm | 220× 73 × 45mm | 240× 73 × 45mm |
| Waterproof rating | IP67 | IP67 | IP67 | IP67 | IP67 | IP67 |
| Safety protection | Overload, over-voltage, over-temperature, overcurrent, and short-circuit protections. | |||||
| Operating temperature | −20 °C to +60 °C, 20% to 90% RH (non-condensing) | |||||
| PCB components | Using all-glass PCB (environmentally friendly, smoldering, high-temperature resistant, and long-life), and brand-new components. | |||||
| Storage temperature | −20 °C to +85 °C, 10% to 95% RH (non-condensing) | |||||
Usage Notes / Installation Tips
- Check the rated voltage and wattage of your device before connecting
- Do not overload beyond the rated capacity
- Use indoors unless specified as IP44 waterproof for outdoor use
- Disconnect power before installation or wiring adjustments
- For continuous heavy load, ensure ventilation (especially for metal/fan-cooled models)
Applications
- LED strip lights and LED drivers
- CCTV cameras and security systems
- Routers, hubs, and communication devices
- Pumps, fans, and small appliances
- DIY electronics projects
- Car accessories (for cigarette lighter models)
- Outdoor inflatables, holiday decorations (for IP44 Class 2 models)
