Description
aClear Series Transparent LED Display Screen P3.91/7.81mm Pixel 1500nits/3500nits/5500nits in 1000x1000mm Aluminum Indoor Type for Glass/Window Display
Package Included
| Version | Package Included |
| 1 Square Meter Screen Only | 1pcs of 1000x1000mm Screen Unit, Total 1 Square Meter |
| 1 Square Meter Screen with Controller Box (Fixed Mounting) | 1pcs of 1000x1000mm Screen Unit, and 1pcs of Novastar TB10 Plus Controller Box |
| 1 Square Meter Screen with Controller Box (Hanging Mounting) | 1pcs of 1000x1000mm Screen Unit, 1pcs 1Meter Hanging Rod, and 1pcs of Novastar TB10 Plus Controller Box |
Order & Logistics
Lead Time: Standard production lead time: 2-5 business days
Shipping Method Options :
- Free Freight: 10–20 days (Air + Ground) — economy air shipping, no additional charge.
- Priority Freight: 7–15 days (Air + Ground) — faster air delivery option at checkout.
All screen are shipped directly from our China headquarters.
DDP Term: Listed shipping methods are offered under DDP (Delivered Duty Paid), meaning customs clearance, duties, and taxes are included. If DDP service is not supported in the destination country, we will coordinate alternative terms (e.g., EXW / FOB) to ensure smooth delivery.
Specification
| Part # | HKaC-P3/7-LA | HKaC-P3/7-MA | HKaC-P3/7-HA |
| Pixel Pitch | H:P3.9/W:P7.8mm | H:P3.9/W:P7.8mm | H:P3.9/W:P7.8mm |
| LED Type |
SMD2121 | SMD1921 | SMD1921 |
| Scan | 16 | 8 | 8 |
| Viewing Distance | >5Meters | >5Meters | >5Meters |
| Cabinet Type | Aluminum | Aluminum | Aluminum |
| Cabinet Size | 1000x1000x80mm | 1000x1000x80mm | 1000x1000x80mm |
| Cabinet Qty./㎡ | 4 | 4 | 4 |
| Cabinet Pixels | 32768dots/㎡ | 32768dots/㎡ | 32768dots/㎡ |
| Power Consumption | Max.750W/㎡ Avg.240W/㎡ | Max.800W/㎡ Avg.260W/㎡ | Max.800W/㎡ Avg.260W/㎡ |
| Input Voltage | 100-240VAC 50/60HZ | 100-240VAC 50/60HZ | 100-240VAC 50/60HZ |
| Brightness | 1500nits | 3500nits | 5500nits |
| Transparency Rate | 60% | 60% | 60% |
| Refresh Rate | 3840HZ | 3840HZ | 3840HZ |
| IP Protection Rating | IP30 | IP30 | IP30 |
| Mean Time Between Failures (MTBF) | 10,000 Hours | 10,000 Hours | 10,000 Hours |
| Lifespan | 100,000 Hours | 100,000 Hours | 100,000 Hours |
| Temperature | -20℃~+40℃ | -20℃~+40℃ | -20℃~+40℃ |
| Humidity | 15%-90%RH | 15%-90%RH | 15%-90%RH |
| Installation Method | Fixed / Hanging | Fixed / Hanging | Fixed / Hanging |
| Operating System | Novastar/Colorlight | Novastar/Colorlight | Novastar/Colorlight |
