IF-3S Series Indoor Flexible LED Module – P2.0 | 320×160mm | SMD | Soft Back Shell with Magnet | 600nits

Save $6.05

Pixel Pitch: P2.0
Package Qty: 1pcs Sample Pack
Price:
Sale price$38.95 USD Regular price$45.00 USD

Description

IF-3S Series Indoor Flexible LED Module – P2.0 | 320×160mm | SMD | Soft Back Shell with Magnet | 600nits

About this item

  • Durable & Reliable – Indoor flexible module with a soft back shell and magnetic mounting for secure installation and easy maintenance.
  • High Precision Visuals – 2.0 mm pixel pitch with 1/40 scan; 160×80 dots per module for smooth, vivid images.
  • Bright & Stable – ≥600 nits brightness; lower lumen depreciation than LCD/DLP for consistent long‑term performance.
  • Wide Viewing – 160° (H) / 160° (V) viewing angles with accurate color reproduction.
  • Seamless Splicing – Create unified large screens without the black gaps common to LCD/DLP walls. Requires receiving card, sending card, control software, and DC 5V power supply.

Package Included

Version Package Included
1pcs Sample Pack 1 × Power Cable
1 × Data Cable
1 × P2.0 320×160mm RGB Full Color LED Display Module
48pcs Standard Pack 48 × Power Cable
48 × Data Cable
48 × P2.0 320×160mm RGB Full Color LED Display Module

Order & Logistics

  • Lead Time: Typically ships within 1–3 business days.
  • Packing: Cardboard box with protective packaging.
  • Shipping: Ships from local warehouses (3–7 days) if available, or from headquarters (7–25 days standard / 3–10 days express).

Structure & Design Features

  • Soft silicone back shell with magnetic mounting for quick assembly and maintenance.
  • Flexible module supports creative curved and spliced installations.

Installation Tips

  • Always disconnect power before installing or servicing the module.
  • Ensure correct polarity for power and data connections.
  • Avoid bending or twisting the PCB beyond the rated tolerance.
  • Use compatible receiving card, sending card, control software, and DC 5V power supply.

Technical Specifications

Specification Value
Pixel pitch 2.0 mm
Module size 320 × 160 mm
Module resolution 160 × 80
Module pixels 12,800 dots
Scan 1/40
Pixel density 250,000 dots/m²
Viewing distance >2 m
LED type SMD1515
Pixel configuration 1R 1G 1B
Brightness ≥600 nits
Contrast ratio 3000:1
Color depth 16-bit
Gray level 16384
Refresh frequency >3840 Hz
Driving IC MBI / ICN / FM
Color uniformity ≥97%
Protection rating IP30
Lifespan ≥100,000 hours
Operating temperature -20°C ~ 60°C
Operating humidity 10% ~ 90%
Voltage 5 V
Viewing angle 160° (H) / 160° (V)
Max power / module 20 W
Blind spot rate ≤0.0003

Applications

  • Indoor: Retail shops, conference rooms, exhibitions, broadcast studios.
  • Creative: Curved splicing, cylindrical screens, artistic installations.
