Description
FCOB Slim Flexible LED Strip Light | 5m (16.4ft) Roll | CRI90 | 3000K / 4000K / 6500K | 480 LEDs/m | 12V 8W | 5mm PCB | Dimmable Indoor IP00 Ribbon
Package Included:
| Version | Package Included |
| 1 Roll × 5 m (16.4 ft total) (Strip Only) | 1 Roll × 5 m (16.4 ft) LED Strip Light Only, Do not include Power Supply and Controller |
| 20 Rolls × 5 m (328 ft total) (Strip Only) |
20 Rolls × 5 m (328 ft total) LED Strip Light Only, Do not include Power Supply and Controller |
| 100 Rolls × 5 m (1640 ft total) (Strip Only) | 100 Rolls × 5 m (1640 ft total) LED Strip Light Only, Do not include Power Supply and Controller |
Order & Logistics:
- Lead Time: Typically 1–3 business days
- Packing: Cardboard box, sealed with anti-static bag
- Shipping: 7-12 days by AIR.
Features:
-
Slim 5mm PCB Design – Ultra-narrow strip perfect for compact spaces, signage, decorative edges, and creative lighting projects.
-
Rich Color Options – Available in whites (3000K / 4000K / 6500K) for versatile applications.
-
Dot-Free Illumination – FCOB technology with 480 LEDs per meter ensures smooth, continuous, and uniform lighting.
-
High CRI90 Lighting – Provides accurate and natural color rendering, suitable for indoor decorative and ambient lighting.
-
Dimmable & Energy Efficient – Operates at 12V DC, only 8W per meter, and fully dimmable for customized brightness control.
Specification:
| Specification | Details |
| Product Name | FCOB Slim Flexible LED Strip Light |
| Length per Roll | 5m (16.4 ft) |
| LED Type | FCOB (Flip Chip-on-Board) |
| Color Options | 3000K / 4000K / 6500K |
| CRI | ≥90 |
| LED Density | 480 LEDs per meter |
| Power Consumption | 8W per meter |
| Input Voltage | 12V DC |
| Cut Section | 50mm (2'') |
| PCB Width | 5mm (slim design) |
| Dimmable | Yes |
| Waterproof Rating | Non-Waterproof, IP00 |
| Package Options | 1 Roll × 5m / 20 Rolls × 5m / 100 Rolls × 5m |
| Applications | Indoor accent lighting, shelves, furniture, signage, decorative edges |
Power Wiring Methods:
How to power/control the strip
When choosing the transformer, the wattage to choose depends on how many pieces light strips it power.And when choosing the transformer, we suggest to use a bigger wattage transformer than the strip rated power to avoid full load working of the transformer. And a big power transformer do no harm to the strip but good for safety.
And a big power transformer do no harm to the strip but good for safety.
Below please find the connection diagram for Single Color Light Strip for reference.
a. Direct Powered by Transformer Run to AC Wall Outlet, On/Off controlled by a Wall Switch
b. Light strip On/Off/Brightness is controlled by Dimmer (Wireless or Hardwire Type available)
#1 Typical connection for one Dimmer to control one string of light bars
#2 One Dimmer to control several strings of light bars by adding Amplifier, and powered by one or several transformers. Note: The strips the Dimmer and Amplifier loaded with cannot exceed their rated max value. And in theory, you can add endless Amplifiers after the Dimmer.
